BATTERY standard XL - 69-201267-032 - Product Detail
BATTERY standard XL
BATTERY standard XL
Article number: 69-201267-032

BATTERY standard XL

Google reviews for dueperthal.com
Item is available for order

The BATTERY line safety storage cabinets are specially designed for safe storage and charging of lithium-ion batteries. With its Type 90 classification and explosive burning of batteries in the interior tested by the independent Fraunhofer Institute, the BATTERY line provides double fire protection. all safety-related components are not subjected to day-to-day dynamic loads and are thus free of attrition and mechanical wear.

  • Safety
    In case of fire - inside or outside - a thermocouple automatically initiates the uninterrupted closing of the doors.

  • Tested backdraft protection (smoke gas explosion).
    In the event of a fire inside the cabinet, the doors are automatically closed and locked to prevent a backdrafts (smoke gas explosion).

  • Alerts via e-mail / SMS with DÜPERTHAL connect
    The monitoring of the backdraft function and the temperatures can be done optionally online incl. alerts via e-mail / SMS or via SMS alert with SMS module via 4G LTE-M network.
Door colors
RAL 7035
PANTONE 389 C
Body colors
RAL 7035
PANTONE 389 C

Specifications

Automatic door closure in case of fire
Automatic door closure in case of fire
Backdraft protection - protection against smoke gas explosions
Backdraft protection - protection against smoke gas explosions
Storing batteries
Storing batteries
Fire containment without extinguishing agents
Fire containment without extinguishing agents
Thermally insulated shelves
Thermally insulated shelves
Type 90 - 90-minute fire protection
Type 90 - 90-minute fire protection
Impact protection through recessed base
Impact protection through recessed base

Technical details

Product range
Safety storage cabinet
Product category
Type 90 - lithium-ion batteries
Line
BATTERY
Version
standard
Size
XL
Type
90
Storage type
passive storage
Functionality
Storage
Earthing connection
Yes
Connection socket
Yes
Z2 012906 0513
DIN EN 14470-1
Yes
Outer width
1194 mm
Outer depth
612 mm
Outer height
2091 mm
Max. load bearing capacity per storage area
75 kg
Max. load
360 kg
Max. total weight
890 kg
Max. volume of single container
30 L
Collection volume
33 L
Max. capacity of li-ion cell
54 Ah
Weight (product)
530 kg
Material of cabinet cladding
Sheet steel
Cabinet colour
RAL 7035
Material of inner lining
Decor panels
Colour of inner lining
RAL 7035
Base
Classical
Base height
95 mm
Base colour
RAL 7015
No. of doors
2 Stk
Kind of door
Wing door
Material of door cover
Sheet steel
Door colour
PANTONE 389 C
Door operation
Classical
Door technology
Classical
Door handle
Bow handle matt nickel
Lock
Cylinder lock
Locking system
Permanent
Locking points
2-point
Backdraft lock
yes
Material of interior fittings
Sheet steel
Colour of interior fittings
RAL 7035
Centre partition wall
Yes
Bottom tray
Fixed
Bottom tray insert
Perforated sheet insert
Storage shelf
Yes
Storage levels
4 Stk
Storage areas
8 Stk
setting height
378 mm
BATTERY standard XL

Certifications and DIN standards

DIN EN 14470-1
DIN EN 16121/16122
DIN 31000
Fraunhofer ICT
DÜPERTHAL connect – Intelligent storage management for hazardous resources.

DÜPERTHAL connect – Intelligent storage management for hazardous resources.

DÜPERTHAL connect is an intelligent solution for managing hazardous material storage. It enables digital networking and monitoring of hazardous material storage via smartphone, tablet, or desktop PC. DÜPERTHAL connect helps companies optimize processes, increase safety, and improve efficiency in handling hazardous substances.

Comparison table

BATTERY standard XL BATTERY standard M BATTERY standard XL
Model size XL M XL
Model type standard standard standard
External width 1194 mm 594 mm 1194 mm
External depth 612 mm 612 mm 612 mm
External height 2091 mm 2091 mm 2091 mm
