ACID pure M - 20-200667-006 - Product Detail
Article number: 20-200667-006

ACID pure M

Google reviews for dueperthal.com
Item is available for order

ACID line pure safety storage cabinets are optimised specifically for the storage of acids and lye in clean rooms. The varied additional functionalities of the cabinets of the ACID line pure increase workplace safety and comfort.

  • Health
    Ventilation on each cabinet level provides optimised air exchange.

  • Safety
    Maximum media resistance from polypropylene interior fittings and collection trays.

  • Working safety
    Height-adjustable collection trays secured against accidental pulling out.
Door colors
silber
Body colors
silber

Specifications

Media resistance for storing aggressive substances
Media resistance for storing aggressive substances
Cylinder lock for secure access
Cylinder lock for secure access
Suitable for clean rooms
Suitable for clean rooms
Smooth wing door technology
Smooth wing door technology

Technical details

Product range
Safety storage cabinet
Product category
Non-flammable media in clean rooms
Line
ACID
Version
pure
Size
M
Storage type
passive storage
Functionality
Storage
Connection socket
Yes
Outer width
595 mm
Outer depth
601 mm
Outer height
1955 mm
Max. load bearing capacity per storage area
40 kg
Max. load
240 kg
Max. total weight
395 kg
Max. volume of single container
12 L
Collection volume
14 L
Weight (product)
150 kg
Material of cabinet cladding
Sheet steel
Cabinet colour
silver
Material of inner lining
PP
Colour of inner lining
white
Base
Without base
Base height
0 mm
No. of doors
1 Stk
Kind of door
Wing door
Material of door cover
Sheet steel
Door colour
silver
Door hinge
Right
Door operation
Classical
Door technology
Classical
Door handle
Bow handle black plastic
Lock
Cylinder lock
Locking system
Open
Locking points
1-point
Material of interior fittings
PP
Colour of interior fittings
white
Bottom tray
Extendable
Storage shelf
Yes
Storage levels
4 Stk
Storage areas
4 Stk
setting height
375 mm
ACID pure M

Certifications and DIN standards

DIN EN 16121/16122
DÜPERTHAL connect – Intelligent storage management for hazardous resources.

DÜPERTHAL connect – Intelligent storage management for hazardous resources.

DÜPERTHAL connect is an intelligent solution for managing hazardous material storage. It enables digital networking and monitoring of hazardous material storage via smartphone, tablet, or desktop PC. DÜPERTHAL connect helps companies optimize processes, increase safety, and improve efficiency in handling hazardous substances.

Comparison table

ACID pure M ACID pure XL
Model size M XL
Model type pure pure
External width 595 mm 1195 mm
External depth 601 mm 601 mm
External height 1955 mm 1955 mm
To the product

Matching products

Filter unit with ventilator and exhaust air monitor unit for acids

Transport trolley f. acids and lye, PP collection tray

Eye emergency station in wall box

Chemical absorber lint-free, 100 cloths

Maintenance and Service

To ensure the longevity and safety of your products, we offer a comprehensive maintenance and service area. Regular inspections and professional maintenance ensure that your devices remain in perfect condition and meet the highest safety standards. Rely on our expertise – we are your competent partner to keep your equipment safe and efficient in the long term. Contact us for a non-binding offer or further information!
