DISPOSAL B pro S - 500022 - Product Detail
DISPOSAL B pro S
DISPOSAL B pro S
Article number: 500022

DISPOSAL B pro S

Google reviews for dueperthal.com
Item is available for order

Specially designed to store different chemical wastes, the DISPOSAL line is equipped with varied additional functions to make work easier and safer. From the great variety of optional extras, choose those which are ideally suited to your laboratory. Create your own individual work environment tailored to your requirements and work processes.

  • Technical ventilation
    Object and air curtain extraction during filling minimise the explosive atmosphere.

  • Safety
    Secure media disposal or transfer in containers up to 20 litres (7.93 gal) in accordance with TRGS 509 (active storage).

  • Working safety
    Conductive powder coating as a standard and integrated earthing system according to TRGS 727.
Door colors
RAL 5010
RAL 7035
Body colors
RAL 5010
RAL 7035

Specifications

Pull-out tray extends automatically
Pull-out tray extends automatically
Interior fittings conductive and connected to the body
Interior fittings conductive and connected to the body
Object extraction during filling
Object extraction during filling
Potential equalization tabs to prevent sparking
Potential equalization tabs to prevent sparking
Safe media disposal or transfer into containers
Safe media disposal or transfer into containers
Type 90 - 90-minute fire protection
Type 90 - 90-minute fire protection
Smooth wing door technology
Smooth wing door technology

Technical details

Product range
Safety storage cabinet
Product category
Type 90 - flammable liquids
Line
DISPOSAL
Version
pro
Design
B
Size
S
Type
90
Storage type
active storage
Functionality
Filling
Earthing connection
Yes
Connection socket
Yes
TÜV Süd certificate no.
Z1A 012906 0521
TÜV-Süd certificate type
GS
Z2 012906 0513
DIN EN 14470-1
Yes
DIN EN 16121/16122
Yes
Outer width
601 mm
Outer depth
594 mm
Outer height
805 mm
Max. load bearing capacity per storage area
45 kg
Max. load
45 kg
Max. total weight
190 kg
Max. volume of single container left side
L
Max. volume of single container right side
20 L
Collection volume left side
L
Collection volume right side
33,6 L
Weight (product)
145 kg
Potential-free contact
Yes
Material of cabinet cladding
Sheet steel
Cabinet colour
electrically conductive gray
Material of inner lining
Sheet steel
Colour of inner lining
RAL 7035
Base
Classical
Base height
35 mm
Base colour
RAL 7015
No. of doors
1 Stk
Kind of door
Wing door
Material of door cover
Sheet steel
Door colour
electrically conductive blue
Door hinge
Right
Door operation
Classical
Door technology
Classical
Door handle
Bow handle matt nickel
Lock
Cylinder lock
Locking system
Open
Locking points
1-point
Material of interior fittings
Sheet steel
Colour of interior fittings
electrically conductive gray
Bottom tray
Extendable
Bottom tray insert
Container insert
Storage levels
1 Stk
Storage areas
1 Stk
setting height
575 mm
Accessories
Yes
Number of level monitors
1 Stk
Number of container
2 Stk
Number of penetrations
1 Stk
Container size
20 L
Sensor Adapter
1 Stk
Yes
DISPOSAL B pro S

Certifications and DIN standards

DIN EN 14470-1
DIN EN 16121/16122
HQ
TÜV-GS
DÜPERTHAL connect – Intelligent storage management for hazardous resources.

DÜPERTHAL connect – Intelligent storage management for hazardous resources.

DÜPERTHAL connect is an intelligent solution for managing hazardous material storage. It enables digital networking and monitoring of hazardous material storage via smartphone, tablet, or desktop PC. DÜPERTHAL connect helps companies optimize processes, increase safety, and improve efficiency in handling hazardous substances.

Comparison table

DISPOSAL B pro S DISPOSAL U pro S DISPOSAL U pro LD
Model size S S LD
Model type pro pro pro
External width 601 mm 601 mm 1100 mm
External depth 594 mm 594 mm 594 mm
External height 805 mm 631 mm 631 mm
